MSD Ignition 7AL-2 Ignition Control (Universeel)
Omschrijving
The 7AL-2 has been a staple in the drag race community for years.
It has now been redesigned with a 40% increase in spark energy!
It also features a popular two-step rev control, LEDs for troubleshooting and convenient terminal strips for easy wiring.
OPERATING SPECIFICATIONS:
Spark Energy: 160 mJ/spark
Primary Voltage: 570 Volts
Secondary Voltage: 47,000 Volts
Spark Series Duration: 20 degree Crankshaft Rotation
RPM Range: 14,000 RPM with 14.4 Volts
Voltage Required: 12-18 Volts, Negative Ground
Current Draw: 6 Amps Per 6,000 RPM; 12 Amps at 12,000 RPM
Weight and Size: 4.85 lbs., 8.25"L x 3.75"W x 5.75"H
