CP Carrillo Pro-H-Beam H11 drijfstangen (B18C motoren)

Each Carillo Aluminum connecting rod is manufactured from a forging, enabling proper grain flow and removal of any surface inclusions or conversions that usually accompanies the forging process. Each lot of forgings is independently inspected and certified. By insuring proper grain flow, the strength and durability of each CP-Carrillo Aluminum rod becomes more consistent and reliable from the first point of manufacturing all the way to the extreme uses in the racing world

Many aspects go into designing a successful Aluminum connecting rod. In this case, it’s all the little things that add up and allow CP-Carrillo to stand alone:

• Greater cross sectional strength
• Superior bolts
• High quality materials (7000 series and Scandium Enhanced Aluminum)
• Arc Serration- not concentric to the bolt hole, allowing oil to escape during assembly and operation
• Lighter design
• Custom options (Pin End burnishing, ASF treatment to name a few)

Specifications:

- ID: 4229
- PN Description: AA-VTC>-65433H
- Type: Straight Blade
- CC: 5.433" / 138.00mm
- Style: PRO-H Beam
- Bolt Size: 3/8
- Bolt Type: WMC
- PE Width: 0.860" / 21.84mm
- BE Width: 0.857" / 21.77mm
- BE Bore: 1.8897" / 47.998mm
- Pin Size: 21mm
- Total/Rotate/Recip (GR): 500/361/139
- FN: H-11 Tool Steel Bolts
